80 Series Heavy-Duty Aluminum Swing Doors for American Homes and Businesses
The Dimax 80 Series swing door system is engineered for residential and commercial applications requiring exceptional structural strength, thermal efficiency, and reliable daily operation. Constructed with high-strength 6063-T5 aluminum profiles at a 2.0 mm wall thickness and a load-bearing capacity of up to 150 kg, this system delivers outstanding stability and durability for high-traffic entrances and statement door designs. Tested to meet international performance standards, it provides effective thermal insulation (Uw 1.4 W/m²·K), sound reduction up to 37 dB, and robust resistance to wind pressure and water penetration, ensuring long-term performance across diverse North American climates.
Key Features:
- Heavy-duty 6063-T5 aluminum frame with 2.0 mm thickness, supporting door panels up to 150 kg for superior strength and long-term stability
- Excellent thermal insulation with Uw 1.4 W/mu00b2u00b7K and sound reduction up to 37 dB for enhanced indoor comfort and energy savings
- High resistance to wind pressure and water penetration, suitable for demanding residential and commercial environments
- Compatible with a wide range of glazing options including single, laminated, double/triple insulated glass for customized thermal and safety performance
- Optional fiberglass or stainless steel flyscreen integration for ventilation and insect control
Dimax Windows & Doors – Certifications & Compliance
Dimax offers a comprehensive range of aluminum window and door systems developed for different international markets. Selected product series and configurations are designed and tested to support compliance with regional standards, including Australian, North American, and European requirements, such as AS2047, NFRC, CSA, Florida Building Code (Miami-Dade), and applicable EN standards. Certification applicability varies by product series, opening type, and configuration. Detailed certification documentation is available upon request.
learn moreDesign Options
Solid-Color Powder-Coated Aluminum Frames
Dimax Our aluminum doors and windows feature high-performance, factory-applied powder-coated finishes, available in a wide range of solid colors. Designed to meet U.S. standards and architectural requirements, these finishes deliver long-lasting durability, excellent color stability, and a clean, modern appearance suitable for residential and commercial applications alike. All finishes are engineered for superior resistance to corrosion, fading, and weathering, making them ideal for diverse climates, including coastal and high-exposure environments.
FOR
PROS
Key Benefits of Our Aluminum Frame Finishes
- • Durable Powder-Coated Finish
- • Factory-applied powder coating provides excellent protection against corrosion, UV exposure, and everyday wear.
- • Color Consistency & Longevity
- • Advanced coating technology ensures long-lasting color performance with minimal fading over time.
- • Designed for U.S. Climate Conditions
- • Suitable for a wide range of environments, from coastal regions to areas with high sun exposure and temperature variation.
- • Low Maintenance
- • Easy to clean with mild soap and water, helping maintain appearance and performance with minimal upkeep.
- • Architectural Versatility
- • Solid-color options complement modern, contemporary, and traditional architectural styles.
80 Series Heavy-Duty Aluminum Swing Doors for American Homes and Businesses
The Dimax 80 Series swing door system is engineered for residential and commercial entrance applications where structural integrity, thermal performance, and reliable operation are essential. Constructed with high-strength 6063-T5 aluminum profiles at a 2.0 mm wall thickness and a load-bearing capacity of up to 150 kg, the system supports door leaf widths from 600 to 1300 mm and heights from 1500 to 3500 mm, accommodating grand entryways and high-traffic commercial openings with ease. Certified to NFPC, CSA, and CE standards, the 80 Series delivers exceptional weather resistance, achieving ultimate wind pressure up to +5040 Pa and water resistance of +1050 Pa—performance that rivals premium hurricane-rated window systems.
Engineered for demanding environments, the 80 Series combines thermal insulation of Uw 1.4 W/m²·K with sound reduction up to 37 dB, ensuring interior comfort and energy efficiency throughout the year. The system accommodates a comprehensive range of glazing options—including single-pane, laminated, double-layer tempered, tempered laminated, and triple-layer tempered glass—allowing architects and homeowners to balance safety, thermal performance, and aesthetic preferences. Finished with premium powder coatings from Interpon or Dulux, backed by 10- or 20-year warranties, and fitted with precision hardware from KIN LONG, BONWAY, or ROTO, each door delivers smooth operation and lasting durability.
Available in single door, double door, or door with sidelight configurations, the 80 Series swing door system reflects Dimax's commitment to quality and project-specific customization. Optional fiberglass or stainless steel flyscreens add ventilation flexibility, while multiple mounting methods—nailing fin, clip/strap, direct bolt, embedded, or brickmould—ensure seamless integration with any construction type. Whether specified for residential entryways or commercial storefronts, the 80 Series delivers the strength, thermal performance, and design adaptability required for modern American architecture.
Customize Your High-Performance Swing Door Solution
Dimax 80 Series swing doors are engineered for residential and commercial entrances where structural integrity, thermal comfort, and architectural expression come together. Constructed with high-strength 6063-T5 aluminum profiles and precision-engineered hardware, the 80 Series creates welcoming entryways that combine lasting durability with clean, modern aesthetics. Whether specified for private homes or light commercial projects, this system delivers reliable performance and smooth everyday operation.
Built as a performance-oriented door system rather than a standard product, the 80 Series supports flexible sizing and configuration to suit diverse façade designs and entrance requirements. Advanced sealing technology and precision hardware work together to deliver exceptional airtightness, water resistance, and structural stability, ensuring comfortable interiors and long-term reliability in any climate. The system accommodates a wide range of glazing options, allowing architects and homeowners to balance privacy, natural light, and thermal performance according to project needs.
With extensive testing and certification to international standards, the 80 Series swing door system reflects Dimax's commitment to quality and project-specific customization. Our team collaborates closely with builders, architects, and developers to tailor frame details, glass configurations, surface finishes, and installation methods—ensuring each entrance solution meets project performance expectations while preserving design intent. Optional flyscreen integration adds ventilation flexibility without compromising clean sightlines.
Our Factory
15,000 m² vertically integrated manufacturing campus with over 1,00 skilled workers, supporting consistent quality control and reliable delivery timelines.
Insulated Glass Assembly
Sealing & Quality Control
Semi-finished Window & Door Frames
Dimax – OEM Partner for Aluminum Window and Door Systems
Dimax offers OEM aluminum window and door solutions with flexible customization options, including size, finish, opening configuration, and brand integration. Our system-based approach supports architectural intent while maintaining consistent performance and manufacturability.
